ML Serisi
The vertical multiline solution as a result of the continuous design evolution and innovation of our packaging lines
The ML-Series is offered in two different models, the ML1000 and ML1200. Both have between 4 and 14 lanes available. The ML Series is especially suited for a multitude of products, granules, powders, and liquids. It is widely used in pharmachuetical, food, as well as the home and personal care sectors. Additionally, we offer automatic downstream equipment, such as conveyors, pick and place robots, as well as cartooning facilities. The machines have the most recent motion technology with integrated PLC functions, which sequences 7 brushless motors.
Packaging Formats
Main Standard Features
One brushless motor for the main film drive system and vertical cutting knives
Two brushless motors for unwinder
Two brushless motors for the vertical seal bars
One brushless motor for horizontal cutting knives
One brushless motor for horizontal seal bars
Mono block tubular steel frame
Integrated electric cabinet
Micro switch protected polycarbonate guardings
18.5” color touch screen
Free access to the entire machine
PLC controlled temperatures in each seal bar
PLC controlled auto lubrication
Splice table in unwinder for quick reel change
Auger cleaning management system
Automatic reel edge aligner in unwinder
TPM features
CIP facilities
Compliance with the primary manufacturing standards
Laser coders and scorers (optional)
ATEX compliance (optional)
Film sterilization system (optional)
Laminar flow (optional)
